Lord Adhesives 8661 Polymer Resistor Composition
Thermoset Lord Adhesives 物性信息：
物理性能 额定值 (公制) 额定值 (英制) 测试方法 布氏粘度 20000 - 40000 cP @Temperature 25.0 °C 20000 - 40000 cP @Temperature 77.0 °F HBT, Spindle CP-51 @ 1rpm 厚度 14.0 - 18.0 microns 0.551 - 0.709 mil
电气性能 额定值 (公制) 额定值 (英制) 测试方法 表面电阻率 900000 - 1.10e+6 ohm 900000 - 1.10e+6 ohm Cured on alumina substrate @ 210oC for 30 min; Termination: LORD 3504 Palladium Silver Conductor; Resistor Geometry: 1mm x 1mm
加工性能 额定值 (公制) 额定值 (英制) 测试方法 固化时间 30.0 min @Temperature 210 °C 0.500 hour @Temperature 410 °F 保质期 6.00 Month @Temperature 25.0 °C 6.00 Month @Temperature 77.0 °F
材料描述 测试方法 外观 Black Consistency Paste Thermal Coefficient of Resistance (ppm/?oC) <1300 Cold TCR measured @ -55 to 25oC; Hot TCR measured @ 25o to 125oC Typical Resistance Change (%) <15 Moisture Resistance: Resistance change on 1mm x 1mm resistor after 1 hour in a pressure cooker <20 Electrostatic Discharge: Resistance change after two 2000 volt pulses on 1mm x 1mm resistor
